Panel thickness: 100mm
Max. height: 17000mm
load-bearing per panel: 1300kgs
Surface finsih: unfinished bare&plywood, melamine, HPL, fabric, PU, wooden ect.
Inner materials: Aluminum keel structure
Top and bottom: 30mm as retractable part
Panels joint: Male and female profile joint together
Suspension: Top track suspension, without any floor track needed
Floor track: No floor track needed
Bearing: Dupont POM roller
...
l Panel thickness: 100mm
l Max. height: 17000mm
l load-bearing per panel: 1300kgs
l Surface finsih: unfinished bare&plywood, melamine, HPL, fabric, PU, wooden ect.
l Inner materials: Aluminum keel structure
l Top and bottom: 30mm as retractable part
l Panels joint: Male and female profile joint together
l Suspension: Top track suspension, without any floor track needed
l Floor track: No floor track needed
l Bearing: Dupont POM roller
Description of the system | |
Item | Durability movable wall with heavy duty steel track |
Applicable height | 17 meters |
STC(dB) | 43-53db |
Description of the partition wall | |
Thickness | 100mm |
Width(min/max) | 680-1230mm |
Height(min/max) | 2000-17000mm |
Suface Material | MDF, Melamine board, Hard fabric, Soft fabric, etc. |
Main Material | 6063-T6 |
Net Wight | 38-55(Kgs/m2) |
Egood Partition Wall,established since 1998, manufacturer and supplier of Green Building Materials, Egood Partition Wall , is committed to provide customers flexible space solution ,offering the wide ranges of Partition walls and Glass walls in the world, targeting large organizations, such as Hotel, Office, Conference room, Restaurant and Public area in the world that required the flexibility, quickly and efficiently reconfigure their space environments.
Features&Benefit
1. High Strength aluminium frame construction for demanding environments.
2. Hinged panels or Single Panel for quick and easy operation.
3. Wide range of surface finishes.
4. Pass door inserted enabling access to neighboring rooms.
5. Parking one or both ends.
6. Top hung and floor with rubber seals achieving excellent soundproof effect.
7. Acoustic test report in Hongkong
With Egood operable partitions you can choose from hundreds of configuration options. Shown below are some examples. The total number of panels in your wall opening depends on your design and the combination of panel height, width and glazing. With a limit of six hinged panels stacking to one side, a maximum width of about 36' is recommended for exterior applications and about 40' for interior applications. With top-hung systems - with additional unhinged paired panels - the maximum number of panels and width is virtually unlimited.
