EGOOD operable partition is made of a high-quality Anodized Aluminum frame with composite materials. The panel has a standard thickness of 65mm/80mm/100mm and a width up to 1230mm.
● Surface finish: HPL,melamine,fabric
● Maximum height: 17000mm
● Soundproof rate: 32-53db
● Track: Heavy duty track
● Operation:sliding and folding
● Height: Up to 15 meter
● Width: 1000-1200mm
● Color: Aluminum sliver
● Materials:6063-T6
● Application: Hotel,banquet, ballroom...
EGOOD operable partition is made of a high-quality Anodized Aluminum frame with composite materials. The panel has a standard thickness of 65mm/80mm/100mm and a width up to 1230mm.
Maximum height can reach 17000mm tall, its vertical seal together with the horizontal top and bottom retractable seals provides excellent acoustic insulation property of maximum STC- 52 in a laboratory setting. Its high performance per dollar value makes it become the most economical suitable for restaurants, schools, offices, religion, hospitals, shopping arcades, and many other indoor application products.
Egood works with Architects, designers, developers, contractors and owners in design product selection, decorative finishes, project management, and after-sales warranty services as her one-stop solution business service.
1.Technical data of Type 65 movable partition :
Model
Weigh
(kg/m)
Fire
Ratin
(min)
STC
Perfor
mance
Specification
Thick
ness (mm)
Width
(mm)
Height
(mm)
Top Seal(mm)
/Pressure
(kg)
Bottom
(mm)
/Pressure
(kg)
LCP
stretch
(mm)
EG65-22
22
60
32db
65
680-1212
2000-4500
22.5/35
22.5/35
140
EG65-38
27
60
38db
65
680-1212
2000-4500
22.5/35
22.5/35
140
EG65-45
25
60
45db
65
680-1212
2000-4500
22.5/35
22.5/35
140
2.Technical data of Type 80 movable partition :
Model
Weigh
(kg/m)
Fire
rating
(min)
STC
Perfor
mance
Specification
Thick
ness
(mm)
Width
(mm)
Height
(mm)
Top seal(mm)
/Pressur
(kg)
Bottom
(mm)
/Pressure
(kg)
LCP
stretch
(mm)
EG80-40
30
60
40db
80
680-1212
2000-5500
22.5/35
22.5/35
140
EG80-45
38
60
45db
80
680-1212
2000-5000
22.5/35
22.5/35
140
EG80-48
47
60
48db
80
680-1212
2000-5000
22.5/35
22.5/35
140
3.Technical data of Type 100 movable partition :
Model
Weight
(kg/m)
Fire
Rating
(min)
STC
Performance
Specification
Thick
ness
(mm)
Width
(mm)
Height
(mm)
Top seal(mm)
/pressure
(kg)
Bottom
seal(mm)
/Pressure
(kg)
LCP
Stretch
(mm)
EG100-43
38
60
43db
100
680-1219
2000-7500
30/40
30/40
140
EG100-48
46
60
48db
100
680-1219
2000-7500
30/40
30/40
140
EG100-53
55
60
53db
100
680-1219
2000-7500
30/40
30/40
140
4.Product Description:
■ Basic MDF face - Standard 9mm -12mm thickness for superior acoustic performance
■ Aluminium frames - Available in colour anodizing, and powder coating
■ Top supported without floor track or guide.
■ customized powder coated color are available. ■ Finishes: Customized painting.
■ Fast delivery and Rich experiences in oversea project installation guide & supervision.
■ Carrier over load: 225-1300Kg.
■ Open Style: Sliding
■ Fixed top sweeps - Retractable seals are required or optional.
■ Light weight and flexible.
5.Details of the aluminum profile:
Egood's double,corrosion-resistant aluminum track systems are easy to install and easier to maintain.
Extruding enables each section to have a uniform shape for superior end-to-end alignment.
Each capacity-certified track is of extruded architectural grade clear anodized 6063-T6 aluminum.
To seal the corner,Egood gets its own design about specially developed conically shaped corner pieces that fit closely together,with high density,strong collision,is not easily deformed even at temperature - 100℃. Compared with other same industry manufacturers,Egood has great superiority in both sealing and noise insulation factor for its products.
The quality of our all products is strictly controlled,only the superior raw material will be used.These are what we always concerned with,please rest assured for our constant strive for excellence.
Available in a wide range of colors of the finish.
6. Structure of the movable partition :
7.View of study:
8.Package:
9.Certificate:
10.Manufacturing process:
▲1/Raw Aluminum Material Cutting
▲2/Base Board Material Cutting
▲3/Drilling
▲4/Frame Assembly
▲5/Rockwool Filling
▲6/Base Board Assembly
▲7/Aluminum Joint Strip fixing
▲8/Screw Tightening
▲9/Wearing Vinyl Strip
▲10/Polishing
▲11/QC Dimension Inspection
▲12/QC Mechanism Inspection
▲13/Finished Production Inspection
▲14/Cleaning
▲15/Packaging
11.Company information:
Foshan is a prefecture-level city in central Guangdong province southern China and ranked as the largest manufacturing base in the pearl river delta.
The production facility of Egood is strategically located in there because of the availability of vast resources Egood has continued to thrive. Because of its excellent product quality and after-sales.To date, it's business coverage has reached not only every area in China but also extended to over 100 countries.
Egood acoustic operable partitions are used to divide meeting rooms, conference rooms, restaurants and banquet halls, etc.
It provides convenient and effective space management solutions, the panels move on a ceiling track with no requirement of floor guides or rails, it has been extensively applied to the hotel industry.
