Fabric Upholstery Movable Partition

■Model Number :Type65/80/100 movable partition
■Matching Track: Type65/80/100 anodized aluminum track system
■Carrier bearing capacity: 225kg/250/380/650kg
■Panel thickness:65/80/100mm
...

Send Inquiry

Egood partition works with Architects,designer, project manager,contractor and owners of project ect. We dedicate to supply first class quality movable partition products with reasonable price for all of our clients, making their idea come true.


Fabric Upholstery Movable Partition


■Model Number :Type65/80/100 movable partition

■Matching Track: Type65/80/100 anodized aluminum track system

■Carrier bearing capacity: 225kg/250/380/650kg

■Panel thickness:65/80/100mm

■Main structure:Anodized aluminum+aluminum Keel

■Accessories material: stainless steel

■Sound insulation :STC32-53db

■Max height: 17000mm

■base board:MDF,plywood;

■Rock wool: 55kg/m3

■Finishes options: acoustic fabric, artificial leather with optional colors.

■Acoustic fabric thickness: 12/15mm

■Package: paper carton,plywood case,wooden pallet

■Price range:usd80-usd180/m2

■Delivery time :4 weeks


Specification for Egood partition wall:


Fabric Upholstery Movable Partition


Egood Movable partition is made of high quality anodized aluminum frame with stainless steel accessories and environmental composite materials. The panels are hung by ceiling track with no requirement of floor guides or rails,the panel has a standard thickness of from 65mm to 100mm and a width up to 1219mm.Maximum height can reach 17000mm tall.


The movable partition consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,it provides excellent acoustic insulation property of maximum STC53db in laboratory condition. The acoustic fabric panel can enhance soundproof performance and optional color makes more more choice for designing. However, there are also many surface finish can be mixed with acoustic fabric finish,they are melamine, mirror steel, wood veneer ect. Standard profile color is clear anodized aluminum,custom powder coating colors are available for matching the surface finish.


Fabric Upholstery Movable Partition


vinyl/melamine covering/solid color or wooden color

woven fabric covering/foam padding/acoustic panel

airtificial leather/foram padding

high pressuare laminate/plastic laminate

nature wood veneer

white board/wall paper

customer’s own materials


Steel structure upon the ceiling:


Fabric Upholstery Movable Partition


Stack systems


Fabric Upholstery Movable Partition


■ Curved corner joint for smoother push and pull

■ The track is equipped with guiding devices for automatic steering turn

■ With aluminum alloy edge covered, better with ceiling suited

■ High-strength steel with high load-bearing capacity

■ Long service life and better safety performance

■ Load capacity 3500kg/m, suitable for partitions of 9 meters or more

■ The highest level is 17 meters domestically.


Product detailed:


Product detailed


Egood's double,corrosion-resistant aluminum track systems are easy to install and easier to intain.Extruding enables each section to have a uniform shape for superior end-to-end alignment.Each capacity-certified track is of extruded architectural grade clear anodized 6063-T6 aluminum.


Product detailed


To seal the corner,Egood gets its own design about specially developed conically shaped corner pieces that fit closely together,with high density,strong collision,is not easily deformed even at temperature - 100℃. Compared with other same industry manufacturers,Egood has great superiority in both sealing and noise insulation factor for its products.


Fabric Upholstery Movable Partition


The quality of our all products is strictly controlled,only the suuperior rawmaterial will be used.These are what we always concerned with,please rest assured for our constantly strive for excellence.


Stacking parking option:


Fabric Upholstery Movable Partition
