Training Room Movable Wall

Training Room Movable Wall

Product name:ASTM standard Training Room Movable Wall
Model:Type65/80/100 movable partition
Panel thickness:65/80/100mm
Model Number:Type65/80/100 anodized aluminum track system
Carrier bearing capacity:225kg/250/380/650kg
Color:silver track
Track Position:top hanging track
Application:light weight partition wall panel
Operation:acrylic partition wall panel
Main structure:Anodized aluminum+aluminum Keel
...

Send Inquiry

Product name:ASTM standard Training Room Movable Wall

Model:Type65/80/100 movable partition

Panel thickness:65/80/100mm

Model Number:Type65/80/100 anodized aluminum track system

Carrier bearing capacity:225kg/250/380/650kg

Color:silver track

Track Position:top hanging track

Application:light weight partition wall panel

Operation:acrylic partition wall panel

Main structure:Anodized aluminum+aluminum Keel



Description of the whole system

 Item

Soundproof Movable partition

 Partition Height

2-17 meters

 Sound Transmission Class(STC)

 32-53db

Description of partition accessories

 Roller

 Imported dupont POM material roller,bearing capacity 225-1300kg

 Track System

 Clear anodized 6063-T6 aluminum double track

 Surface finish option

 MDF,melamine,HPL,fabric,PU,wood veer

 Junction

 "T"junction, "L" juntion, cross/ "X" juntion

Glass wool  density inside

64kg/m3

Interior profile

Wooden, aluminum, steel

Application

Hotel, banquet hall, ballroom , conference room, classroom, function hall, auditorium



Soundproof Movable partition Features:

1- 65mm ,85mm, 100mm aluminum frame thickness panel ,Max height up to 15 meters.

2-Top supported without floor track or guide, only have track on the ceiling.

3- clear anodized extruded aluminum tracks and frames,customized powder coated color are available.

4- Sound insulation certificate :STC 32db to  52db, ASTM standard of acoustic tested in HongKong.

5- Available in wide range of finishes, melamine ,fabric/PU leather, HPL, printing etc.

6- Fast delivery and Rich experiences in oversea project installation guide & supervision.


The movable partitions consist of a series of concave/convex profile interlocking flat panels and the fast set retractable top and bottom seals ,its provide excellent acoustic insulation property of from STC-32 to 53 in laboratory setting.

Its high performance per dollar value and the easiest in-field operation makes it very suitable for Hotel, banquet hall, conference room ,ballroom, muti-function hall, restaurant,classroom,office,religion,dance studio ,shopping arcades and many other place where seek for space divide with good soundproof performance .



There are wide of range face finishes are available :melamine faced MDF or

Plywood, fabric, carpet, fabric, artificial, leather,wood veneer, high pressure laminate,Formica ,acoustic panel,white board ect., Panels can also be supplied unfinished for field decoration,Standard frame color is clear anodized aluminum,custom powder coating colors are available.



 EGOOD partition works with Architects,designer,developers,contractores and owners in design product selection,decorative finishes,project management and after-sales warranty services as her one-stop solution business service.



Movable Partition internal structure diagram:

2021012916223010ec823d1eaa47269ef96b659a6c405b

Accessories for operable partitions:

105

Movable partition parking layout:

2021012814111113946939d14d487ca102fdd90ad06c81
